Precision Fabricators was contracted to deliver all of the carbon steel pipes for a new expansion of the existing chilled water systems at a pharmaceutical plant. Using the latest technology of 3D scanning, a Faro Focus 3D scanner was used to acquire all existing site conditions in point clod format, which then was imported into a 3D model for piping isometrics coordination. Precision's spatial coordinators then generated 3D piping isometrics, duly coordinated with the gathered field data, which then were sent to the shop for fabrication.
Prefabrication Insights:
Precision Fabricator's Orbital Welding facilities are capable of performing automatic autogenous (GTAW, T1G) welding of tubes, fittings (such as Tri-clover, Alfa Laval, United, Advance or Top Line), elbows, return bends and think wall pipe from 1/8" to 4" O.D. It can also weld SCH. 10 stainless steel pipe. The Programmable Controls, Power Source and the range of tube sizes that can be welded, make this the most capable tube weld system available.
